Main Features -

IEEE 802.3bt PoE++ Solutions

• The product adopts IEEE 802.3bt PoE++ standard technology, provides up to 95 watts per port output as an ideal solution for higher power consumption network PDs, such as POS system, digital signage.

Dual Power Input for High Reliability

• Automatically switch to secondary power input when primary power input fails, ensuring continuous operation without down time.

• Redundant power supply reduces possibility of single-point-of-failure.

Environmentally Hardened Design

• With a compact metal housing with an IP40 rating

• Environmentally hardened for direct deployment in difficult unconditioned out-of-plant and roadside installations.

• Extended ambient operating temperature range: -40 ̊ C to +75 ̊ C



Other Features -

• Converts 10/100/1000Base-TX to 1000Base-SFP

• Supports external 1000Base-SFP

• Supports Full/Half-duplex, Auto MDI/MDIX

• 10K Bytes Jumbo Frame

• Supports DIN-Rail and Wall-mount installation

​

​
