HMC-HDM-F1SPp
Hardened Grade 10/100Base-TX (PoE+) to 100Base-SFP Ethernet Media Converter
Dual Power Input for High Reliability
-
Automatically switch to secondary power input when primary power input fails, ensuring continuous operation without down time.
-
Redundant power supply reduces possibility of single-point-of-failure.
Environmentally Hardened Design
-
With a compact metal housing with an IP40 rating
-
Environmentally hardened for direct deployment in difficult unconditioned out-of-plant and roadside installations.
-
Extended ambient operating temperature range: -40 ÌŠ C to +75 ÌŠ C
Other Features
-
Complies with 802.3af/at PSE standard (30W)
-
10/100Mbps-Full/Half-duplex, Auto-negotiation, Auto MDI/MDI-X
-
Support external SFP
-
Aluminium case
-
512Kbits Packet Buffer
-
Full wire-speed forwarding rate
-
Support Wall-mount installation
Frequently Asked Questions (FAQ)
1. What is the main function of the HMC-HDM-F1SPP?
-
The HMC-HDM-F1SPP is an industrial-grade PoE+ media converter that connects 10/100Base-TX Ethernet devices to 100Base-FX fiber networks while providing Power over Ethernet (PoE+) capabilities for powering end devices like IP cameras or wireless access points.
2. Does the HMC-HDM-F1SPP support redundant power inputs?
-
Yes, the HMC-HDM-F1SPP supports dual 12~48VDC redundant power inputs to ensure reliable and continuous operation even if one power source fails.
3. What types of environments is the HMC-HDM-F1SPP suitable for?
-
It is designed for harsh industrial environments, with an extended operating temperature range, a rugged metal casing, and hardened components to handle electrical noise, vibration, and extreme temperatures.
4. Can the HMC-HDM-F1SPP deliver PoE+ power while converting Ethernet to fiber?
-
Yes, it simultaneously performs Ethernet-to-fiber media conversion while delivering IEEE 802.3at PoE+ power (up to 30W) to connected powered devices such as IP cameras or wireless access points.
